Type | Unit | GMC4022 |
Worktable | ||
Worktable (length*width) | mm | 4000*1800 |
Maximun Load of table | kg | 19000 |
T-slot | mm | 9-22*200 |
Processing scope | ||
Gantry width | mm | 2200 |
Travel for X/Y/Z axis | mm | 4200*2200*1000 |
Distance from spindle nose to table surface | mm | 200-1200（T/L）/110-1110（R） |
Drive feed | ||
Fast feed speed（ X/Y/Z） | m/min | 10/15/12 |
Spindle | ||
Maximum spindle speed | r.p.m | 6000/5000（R） |
Spindle taper | BT50 | |
Spindle motor | kw | 22/26 |
Max.torque of spindle | Nm | 278(Belt)/892(ZF)/1226（R） |
Tool magazine（Optional） | ||
Capacity of tool magazine | 24 | |
Max. tool diameter | mm | 100/200 |
Max. tool length | mm | 300 |
Max. tool weight | kg | 15 |
Precision | ||
Positioning accuracy（ X/Y/Z） | mm | 0.025/0.02/0.016 |
Repeated Positioning accuracy（ X/Y/Z） | mm | 0.016/0.012/0.01 |
Others | ||
Total power capacity | kva | 55 |
Weight | kg | 37000/39000（R） |
Floor area (length*width*height) | mm | 10520*5600*5075 |
