Specification | 型号 | Model | |
C6233×1000/1340 | C6236×1000/1440 | C6236V | |
Capacity | |||
Swing over bed | 330mm(13″) | 356mm(14″) | 356mm(14″) |
Swing over cross slide | 195mm(7-5/8″) | 220mm(8-5/8″) | 220mm(8-5/8″) |
Swing in gap diameter | 475mm(18-11/16″) | 506mm(20″) | 506mm(20″) |
Valid length of gap | 145mm(5-11/16″) | ||
Admits between | 1000mm(40″) | ||
Width of bed | 206mm(8″) | ||
Headstock | |||
Spindle nose | D1-4 | ||
Spindle bore | 38mm(1-1/2″) | ||
Taper of spindle bore | MT No.5 | ||
Range of spindle speed | 16 changes 45～1800r/min | 30～550r.p.m 155～3000r.p.m | |
Feed and threads | |||
Compound rest travel | 95mm(3-3/4″) | ||
Cross slide travel | 180mm(7″) | ||
Max. section of tool | 16mm×16mm(5/8″×5/8″) | ||
Lead screw thread | 8T.P.I. or 4mm | ||
Longitudinal feeds range | 0.0012″～0.0294″/rev（Inch lathe） or 0.043～0.653mm/rev （Metric lathe） | ||
Cross feeds range | 0.0004″～0.01″/rev（Inch lathe） or 0.027～0.413mm/rev（Metric lathe） | ||
Threads metric pitches | 0.45～7.5mm（Inch lathe） or 0.4～7mm（Metric lathe） | ||
Threads inch pitches | 4～112T.P.I. （Inch lathe）or 4～56T.P.I. （Metric lathe） | ||
Tailstock | |||
Quill diameter | 45mm(1-3/4″) | ||
Quill travel | 120mm(4-3/4″) | ||
Quill taper | MT No.3 | ||
Motor | |||
Main motor power (double speeds) | 1.5/2.4kW(2/3HP) | ||
Coolant pump power | 0.04kW | ||
Dimension and weight | |||
Overall dimension (L×W×H) | 182×74×124cm | 182×74×125cm | 182×74×125cm |
Packing size (L×W×H) | 193×76×158cm | 193×76×158cm | 193×92×159cm |
Net weight | 700kg | 730kg | 750kg |
Gross weight | 820kg | 860kg | 880kg |
