Specification | Model | |||||
C6241×1000 | C6241V×1500 | C6246×2000 | C6246V×1000 | C6246V×1500 | C6246V×2000 | |
Capacity | ||||||
Swing over bed | 410mm(16") | 460mm(18") | ||||
Swing over cross slide | 220mm(8-13/16") | 270mm(10-3/4") | ||||
Swing in gap diameter | 640mm(25-1/8") | 690mm(27-1/8") | ||||
Distance between centers | 1000mm(40") | 1500mm(60") | 2000mm(80") | 1000mm(40") | 1500mm(60") | 2000mm(80") |
Valid length of gap | 165mm(6-1/2") | |||||
Width of bed | 300mm(11-13/16") | |||||
Headstock | ||||||
Spindle nose | D1-6 | |||||
Spindle bore | 58mm(2-1/4") | |||||
Taper of spindle bore | No.6 Morse | |||||
Range of spindle speed | 12 changes, 25～2000r/min | |||||
Feeds and threads | ||||||
Compound rest travel | 128mm(5") | |||||
Cross slide travel | 285mm(11-1/4") | |||||
Max.section of tool | 25×25mm(1"×1") | |||||
Lead screw thread | 6mm or 4T.P.I. | |||||
Longitudinal feeds range | 42 kinds, 0.031～1.7mm/rev(0.0011"～0.0633"/rev) | |||||
Cross feeds range | 42 kinds, 0.014～0.784mm/rev(0.00033"～0.01837"/rev) | |||||
Threads metric pitches | 41 kinds, 0.1～14mm | |||||
Threads imperial pitches | 60 kinds, 2～112T.P.I. | |||||
Threads diametral pitches | 50 kinds, 4～112DP | |||||
Threads module pitches | 34 kinds, 0.1～7MP | |||||
Tailstock | ||||||
Quill diameter | 60mm(2-5/16") | |||||
Quill travel | 130mm(5") | |||||
Quill taper | No.4 Morse | |||||
Motor | ||||||
Main motor power | 5.5kW(7.5HP) 3PH | |||||
Coolant pump power | 0.1kW(1/8HP) 3PH | |||||
Dimension and weight | ||||||
Overall dimension(L×W×H) | 220×108×134cm | 275×108× 134cm | 325×108× 134cm | 220×108× 137cm | 275×108× 137cm | 325×108× 137cm |
Packing size(L×W×H) | 225×112×162cm | 280×112× 156cm | 330×113× 156cm | 225×112× 162cm | 280×112× 156cm | 330×113× 156cm |
Net weight | 1580kg | 1745kg | 1900kg | 1645kg | 1810kg | 1965kg |
Gross weight | 1845kg | 2050kg | 2230kg | 1910kg | 2115kg | 2295kg |
