SPECIFICATIONS | Units | CK6163E | CK6163E |
Manual | HYD. | ||
Swing over bed | mm | 630 | |
Swing over cross slide | mm | 350 | |
Distance between centers | mm | 1000/1500/2000/3000/4000/5000/6000 | |
Guideway width | mm | 550 | |
Max. load capacity | T | 3 | |
Spindle bore | mm | 104 | |
Spindle bore taper | - | Metric φ120/MT5 | |
Spindle nose type | - | C11 | |
Spindle speed steps | - | VF. 3 steps | HYD. 4 steps |
Spindle speed range | rpm | 10-1000 | 17-1000 |
Chuck | mm | φ315 3-jaw manual | |
Turret/tool post | - | Electric 4 position | |
Tool size | mm | 32 x 32 | |
X axis travel | mm | 320 | |
Z axis travel | mm | 850/1350/1850/2850/3850/4850/5850 | |
X axis rapid traverse | mm/min | 4000 | |
Z axis rapid traverse | mm/min | 6000 | |
Tailstock quill diameter | mm | φ100 | |
Tailstock quill taper | - | MT5 | |
Tailstock quill travel | mm | 250 | |
Main spindle motor | kw | 11 | |
Coolant pump motor | kw | 0.125 | |
Weight for 1000 | kg | 3700 | |
Weight for 1500 | kg | 4100 | |
Weight for 2000 | kg | 4500 | |
Weight for 3000 | kg | 5300 | |
Weight for 4000 | kg | 6100 | |
Weight for 5000 | kg | 6900 | |
Weight for 6000 | kg | 7700 | |
Dimension for 1000 | mm | 3300x1750x1850 | |
Dimension for 1500 | mm | 3800x1750x1850 | |
Dimension for 2000 | mm | 4300x1750x1850 | |
Dimension for 3000 | mm | 5300x1750x1850 | |
Dimension for 4000 | mm | 6300x1750x1850 | |
Dimension for 5000 | mm | 7300x1750x1850 | |
Dimension for 6000 | mm | 8300x1750x1850 | |
